Architectural Cubic 40 (AC40) Windows/Doors
Product Description
The combination of flush surfaces and square shapes gives the AC40 suite a clean modern aesthetic. Designed for robust performance with a larger than normal glazing capacity to allow for modern design requirements and increased glass spans.
Application
High-end residential or architectural applications where quality, durability and high performance are paramount. Suitable for mid to high end homes, high rise apartments, hotels, commercial and industrial projects. Best when;
- modern, flat aesthetic is required
- square stopped gib internal finishes are desired
- direct through frame fixing is sought providing added structural integrity
Can be integrated with other Fairview Architectural ranges and our commercial product for maximum design advantages.
Features overview
- Full range of mullions and transoms including internal box stiffening or external fins.
- Bevelled or square glazing bead options for optimal aesthetic appearance.
- Hinged/Bifold & Sliding doors can be designed up to 2700mm height in most locations.
- Hinged and bi-fold doors have 55mm thick heavy duty panels.
- Available in 77mm or 119mm stile widths.
- Bi-fold doors can be bottom rolling with the weight carried on the sill; or top hung when the lintel is designed to receive the panel loads.
- Sliding doors have heavy duty roller options for panels up to 300kg.
- Optional anodised tracks for long term performance.
- Sashes can be added without expensive sub-frames.
- Heavy duty mullion options that can span up to 3m high.
- Condensation drainage channel with anti-blow-back valve for high water egress performance.
- Standard 19mm weather facing flange. 35mm flange option available for increased cladding cover.
Glazing options
40mm glazing platform provides a glazing capability up to 28mm.
Product range consisting of:
- Fixed, awning and casement windows
- Bi-fold windows (open-out)
- Sliding windows (horizontal or vertical)
- Hinged doors (both open-in or open-out)
- Bi-fold doors (bottom rolling panels up to 100kg)
- Sliding doors (inside or outside sliding panels)
- Stacking doors (inside or outside sliding panels)
- Over the wall sliding/stacking panels. Unlimited and multi directional panels operate in track system providing consistent sightlines.
Finishes/Colours
Powdercoated: huge range of standard and non-standard colours.
Anodised: standard colour options are silver, black and bronze, 12, 20 and 25 micron thickness. Other colours and thicknesses are available.
EUROWOOD™: a range of wood-grain finishes available.
Hardware
Stella, Kanso and Verta hardware options available.
